| Overview | |
|---|---|
| Video Output Port | Ethernet, Micro-HDMI |
| Control Signal Input Port | S.Bus, UART, Ethernet UDP/TCP |
| High Accuracy 3-Axis Stabilization | Yaw, Pitch, Roll |
| Working Voltage | 11~25.2V |
| Power Consumption | Average 5W, Summit 12W |
| Waterproof Level | IP4X |
| Working Temperature | -10~50℃ |
| Dimension | 132x100x180mm (Quick Release Board Included) |
| Weight | 668g (Quick Release Board Included) |
| ZR30 Quick Release Board | |
| Dimension | 82x65x20mm |
| Weight | 38g |
| Gimbal | |
| Angular Vibration Range | ±0.01° |
| Controllable Pitch Angle | -90°~+25° |
| Controllable Yaw Angle | -270°~+270° |
| Roll Angle | -45°~+45° |
| Camera | |
| Lens | 30X Optical Zoom (180X Hybrid Zoom) |
| Focal Length | 4.5~148.4mm (±5%) |
| Image Sensor | 1/2.7 Inch Sony CMOS, 8MP Effective Resolution |
| Aperture | F1.3~2.8 (±5%) |
| FOV | Without Zoom: Diagonal 65.4°, Horizontal 58.1° |
| 30X Optical Zoom: Diagonal 2.5°, Horizontal 2.1° | |
| Video Recording Resolution | 4K (4096x2160) @25fps |
| 2K (2560x1440) @30fps | |
| 1080P (1920x1080) @30fps | |
| 720P (1280x720) @30fps | |
| Still Photo Resolution | 4K (3840x2160) |
| Video Storage Bitrate | 12Mbps (H.265 Codec) |
| File Storage Format | FAT32, ExFAT |
| Image Format | JPG |
| Video Format | MP4 |
| Supported MicroSD Cards | MicroSD Class10, Max128GB |
| Still Photography Mode | Single |
| Metering Mode | Evaluative Metering |
| White Balance | Automatic |
